Printed Circuit Boards

PCB's Flex and Rigid Flex

Knowing who to turn to when you have a complex board design and a short deadline is critical. Our team of engineering experts and manufacturers can help. Whether you're just laying out the design of your board or just need us to quote your completed design, we have the solution for you.

Principals



Summit Interconnect Overview

Technology & capabilities: Multi-layer rigid to 30+ layers, flex, rigid flex, backplanes, micro VIA's, blind & buried VIA's, lazer drilling, fine lines/spacing, selective gold plating, impedance control, exotic materials, metal core, heavy copper, DFM & DFT.

  • ROHS compliant.

  • Quick turns, prototypes, low to high volume production.

  • Test services: 100% electrical test, all products, flying probe test, AOI test.

  • Certifications: ISO 9001, AS9100C, MIL-P-55110, MIL-P-50884, IPC class 2 & 3, ITAR certified.

  • Manufacturing location: Anaheim and Orange Calif.



Valley Syncom Overview

Woman owned Small Business, Family operated since 1972. Valley Circuits dba Valley Syncom Circuits has become one of the most prestigious board houses in Southern California. Specializing in printed circuit boards for Defense, Aerospac & Medical Devise Industries. Proudly standing behind more than three decades of experience. VSC provides expert knowledge and has a proven record of excellence.

Printed Circuit Board Types:

  • Rigid Flex
  • Rigid
  • Flex
  • Single and Double Sided
  • Multi-Layer
  • Back Plane Controlled Impedance
  • Metal Core Boards

Materials used per IPC-4101:

  • Teflon - GF - GI
  • Other Exotic Materials

Services:

  • Assembly:
  • Through Hole
  • Surface Mounted
  • Small to Medium Run Capability
  • Military and Aerospace Applications
  • Turn Key & Consignment

In-house Capabilities:

  • Artwork & Tooling
  • CAD Engineering
  • Interlayer Process & Lamination
  • Drilling / Blind & Buried Vias
  • AOI (Inner Layer Inspection)
  • Plasma Etch Back
  • Electroless Copper Plating
  • Outer Layer Print
  • Electrolytic Copper Plate
  • Etch & Strip
  • LPI Mask
  • (Liquid Photo Imageable Solder)
  • Legend (Nomenclature)
  • HASL (Hot Air Solder Level)
  • Final Routing
  • Electrical Test
  • (Flying Probe & Bed of Nails)
  • Inspection Quality Audit
  • Heatsink Bonding

Certifications:

  • ISO 13485:2003
  • ISO 9001: 2008 and AS9100C
  • ITAR 2018
  • MIPRF 55 110H

Mission Statement

Our mission is to provide you with solutions for your engineering, procurement and manufacturing needs. Simply put: We want to be your partner in success. We invite you to contact us today. Thank you for the privilege to to serve you!

Contact Us

  • 3835 E. Thousand Oaks Blvd. Suite 279
    Westlake Village, CA 91361
  • (818) 581-9010
